LC-MAXIMD005
Brighteness & Motion Sensor
Function
- Illuminance value cycle output
- 2-way control luminance channel, output 1bit, 4 bit, 1byte data
- Infrared motion trigger control
- Infrared motion and brightness logic
- Infrared motion Master-Slave
- The output control function of illumination and infrared movement is enabled or disabled by the object
- The combination of illumination & movement controls the function of the light
- Infrared motion, illumination
Parameters
- Bus input 21-30V DC, bus power supply Bus current ≤12mA Bus power ≤360mW
- Sensing distance H 2.5m~3.5m Radiation range:≥10m Material ABS
- Dimension H 76mm, D 76mm Hole Installtion 62-72mm
- Installtion Embedded
- Installation Weight About 0.05KGS
- Operating temperature -5°C- 45°C
- Storage temperature – 20°C- 70°C Relative humidity Max 90%
